270 XT MAX Awning Mk2

Freestanding 270° 4WD Awning | 12m² / 129 sq ft of Shade | Two Hinge Points

Pull up, unzip, swing it out. The 270 XT MAX Awning Mk2 throws 12m² (129 sq ft) of shade down the side and around the back of your rig in under 60 seconds — no poles, no guy ropes, no mucking around. Twin hinge points and a forward-folding front section wrap the coverage past your rear door, so your camp kitchen, your gear and your mates all stay out of the sun.

Built on a B-Tech™ Alloy frame with stainless steel hinges and 315gsm (9.3oz) ripstop polycotton canvas, it stands freestanding on corrugated tracks, coastal salt air and red dust country. Choose left or right hand fitment. Backed by a 2-year conditional warranty.

Built Stronger. Built for Adventure. Built for Life.

Read MoreRead More
SKU:4AXTML International Store Finder

270 XT MAX Awning Mk2 — the biggest freestanding shade in the Bush Company range

Twelve square metres. That's the number that matters. The 270 XT MAX Awning Mk2 deploys 12m² (129 sq ft) of UV- and water-resistant shade across a 6067mm x 3100mm footprint (19'11" x 10'2"), wrapping your vehicle from the front door right around the rear — and it does it without a single upright pole touching the ground.

You're not pegging out a tarp. You're rolling into camp, swinging two trussed arms into position, and getting on with the fishing.

What makes the MAX different from the 270 XT Mk2

This is the question worth answering before you spend. Both are freestanding 270° awnings. The difference is in the hinges.

The 270 XT Mk2 runs a single pivot point — fast, simple, 8m² (86 sq ft), and brilliant for solo and duo touring. The 270 XT MAX Mk2 runs two hinge points and a forward-folding front section. That second hinge is what pushes coverage out to 12m² (129 sq ft) and lets the canvas reach further around the back of the vehicle, clearing canopy doors and covering a full rear kitchen setup.

More shade, more rear coverage, more room under it. The trade-offs are honest ones: 33.5kg (73.9 lb) on your roof instead of 27.8kg (61.3 lb), and a 1.9m (6'3") minimum bracket spacing instead of 1.4m (4'7"). If your rack is shorter than 1.9m (6'3") or your roof payload is tight, the 270 XT Mk2 is the smarter buy. If you're running a wagon, troopy, van or canopied ute and you want the whole camp covered, this is the one.

Freestanding means freestanding

No poles. No guy ropes in calm weather. Nothing to trip over at 2am, nothing to sink into soft sand, nothing to rattle loose on a corrugated track.

The B-Tech™ Alloy trussed arms carry the load themselves. That's the whole point of a truss — the geometry does the work, so the canvas stays tensioned and the frame stays put without ground support. Setup is a one-person job in under 60 seconds. Pack-down is the same in reverse, and the oversized PVC bag means you're not wrestling canvas back into a sleeve while the weather closes in.

When it does blow up, peg it out. The 270 XT MAX Mk2 is rated to 50km/h (31 mph) gusts when correctly pegged and guyed, and it ships with the guy ropes and pegs to do it.

B-Tech™ Alloy frame, engineered for the long haul

The frame is built from The Bush Company's exclusive B-Tech™ Alloy extrusion with stainless steel hinges and a powder-coated finish. Extruded alloy resists the torsional flex that kills welded frames on corrugations. Stainless hinges resist the salt that eats plated hardware on beach runs.

This is buy-once gear. The frame is the part you'll never think about again — which is exactly how it should be.

Australian owned, tested globally. Manufactured in South Africa in the same conditions that punish gear the way outback Australia does, then proven on Australian tracks by Australian tourers.

One seam. That's it.

Seams leak. Every stitched line across a canvas is a potential entry point, and most awnings on the market have several.

The 270 XT MAX Mk2 uses 315gsm (9.3oz) ripstop polycotton canvas cut from an ultra-wide roll, which lets us build 12m² (129 sq ft) of canopy with a single seam. Fewer seams, fewer leak paths, drier camp. The canvas is pre-treated for UV stability and mould and mildew resistance, with triple-stitched sleeves and reinforced attachment points at every load-bearing corner.

Wet it down before your first trip. The poly-cotton core spun thread swells and seals the stitch holes — a five-minute job that sets the canvas up for years of four-season use.

Build it out with walls

A 50mm (2") Velcro loop strip runs the full internal edge, ready for The Bush Company's canvas and mesh wall kits.

Run one wall as a windbreak on the exposed side. Run mesh to keep the sandflies out on a Cape York evening. Or close the whole thing in and turn 12m² (129 sq ft) of shade into a proper enclosed room with a view. The modular ecosystem is the point — you buy the awning once and shape it to the trip.

Mounting to your rig

The 270 XT MAX Mk2 ships with three heavy-duty adjustable L-brackets. One mounts to the stainless steel headstock at each end, with the third going in the middle for support across the span.

You need a minimum of 1.9m (6'3") between your front and rear mounting points. Most full-length platform racks, load bars and canopy racks clear this easily; some systems (the ARB base rack, for example) need additional hardware. The packed profile is 2300mm long x 230mm high (7'7" x 9.1"), so it sits low and tucks inside a standard roof line without overhang.

Running a Bush Company rooftop tent? The optional Awning To Tent brackets mount the awning directly to the tent for a tidy, low-profile touring setup.

Compatible with: dual-cab utes, 79 Series and wagon platforms, Troop Carriers, van conversions, canopied utes, and camper trailers — anywhere you can achieve 1.9m (6'3") bracket spacing and the roof payload to carry 33.5kg (73.9 lb).

Before you buy: check your roof payload

Straight talk. At 33.5kg (73.9 lb) plus brackets, plus rack, plus whatever else is up there, the 270 XT MAX Mk2 is a genuine payload decision. Check your vehicle's dynamic roof load rating before you order. If the numbers are tight, look at the 270 XT Mk2 (27.8kg / 61.3 lb) or the 180 XT MAX (26.5kg / 58.4 lb) instead — both run the same canvas and the same B-Tech™ Alloy DNA.

We'd rather you get the right awning than the biggest one.

Usage guidance

  • Secure the front and rear non-trussed arms with the supplied guy ropes and pegs in all conditions to prevent upward movement.
  • In heavy rain, run guy ropes off 1-tonne (2,205 lb) webbing straps between the arms to shed water and stop pooling.
  • Don't leave it deployed during snowfall — wet snow load stretches canvas.
  • Wet the canvas down thoroughly before first use.
  • Read the Care and Maintenance instruction on this website.

Key features

  • Freestanding 270° deployment — no poles required
  • 12m² (129 sq ft) of coverage across a 6067mm x 3100mm (19'11" x 10'2") footprint
  • Two hinge points with forward-folding front section for rear-of-vehicle coverage
  • B-Tech™ Alloy trussed arms with stainless steel hinges
  • 315gsm (9.3oz) ripstop polycotton canvas, single-seam construction, UV and mould treated
  • Setup and pack-down in under 60 seconds, one person
  • Rated to 50km/h (31 mph) gusts when pegged and guyed
  • 450gsm (13.3oz) PVC tonneau storage bag, oversized for easy repacking
  • 50mm (2") Velcro loop strip for modular wall kits
  • Three heavy-duty adjustable L-brackets included
  • Left or right hand fitment
  • Packed size 2300mm x 180mm (7'7" x 7.1"), weight 33.5kg (73.9 lb)
  • 2-year conditional warranty

Who it's for

Long-range tourers, families and overland crews running wagons, troopies, vans or canopied utes who want maximum shade around the whole rig, have 1.9m (6'3") of rack to mount it and the payload to carry it.

Description

270 XT MAX Awning Mk2 — the biggest freestanding shade in the Bush Company range

Twelve square metres. That's the number that matters. The 270 XT MAX Awning Mk2 deploys 12m² (129 sq ft) of UV- and water-resistant shade across a 6067mm x 3100mm footprint (19'11" x 10'2"), wrapping your vehicle from the front door right around the rear — and it does it without a single upright pole touching the ground.

You're not pegging out a tarp. You're rolling into camp, swinging two trussed arms into position, and getting on with the fishing.

What makes the MAX different from the 270 XT Mk2

This is the question worth answering before you spend. Both are freestanding 270° awnings. The difference is in the hinges.

The 270 XT Mk2 runs a single pivot point — fast, simple, 8m² (86 sq ft), and brilliant for solo and duo touring. The 270 XT MAX Mk2 runs two hinge points and a forward-folding front section. That second hinge is what pushes coverage out to 12m² (129 sq ft) and lets the canvas reach further around the back of the vehicle, clearing canopy doors and covering a full rear kitchen setup.

More shade, more rear coverage, more room under it. The trade-offs are honest ones: 33.5kg (73.9 lb) on your roof instead of 27.8kg (61.3 lb), and a 1.9m (6'3") minimum bracket spacing instead of 1.4m (4'7"). If your rack is shorter than 1.9m (6'3") or your roof payload is tight, the 270 XT Mk2 is the smarter buy. If you're running a wagon, troopy, van or canopied ute and you want the whole camp covered, this is the one.

Freestanding means freestanding

No poles. No guy ropes in calm weather. Nothing to trip over at 2am, nothing to sink into soft sand, nothing to rattle loose on a corrugated track.

The B-Tech™ Alloy trussed arms carry the load themselves. That's the whole point of a truss — the geometry does the work, so the canvas stays tensioned and the frame stays put without ground support. Setup is a one-person job in under 60 seconds. Pack-down is the same in reverse, and the oversized PVC bag means you're not wrestling canvas back into a sleeve while the weather closes in.

When it does blow up, peg it out. The 270 XT MAX Mk2 is rated to 50km/h (31 mph) gusts when correctly pegged and guyed, and it ships with the guy ropes and pegs to do it.

B-Tech™ Alloy frame, engineered for the long haul

The frame is built from The Bush Company's exclusive B-Tech™ Alloy extrusion with stainless steel hinges and a powder-coated finish. Extruded alloy resists the torsional flex that kills welded frames on corrugations. Stainless hinges resist the salt that eats plated hardware on beach runs.

This is buy-once gear. The frame is the part you'll never think about again — which is exactly how it should be.

Australian owned, tested globally. Manufactured in South Africa in the same conditions that punish gear the way outback Australia does, then proven on Australian tracks by Australian tourers.

One seam. That's it.

Seams leak. Every stitched line across a canvas is a potential entry point, and most awnings on the market have several.

The 270 XT MAX Mk2 uses 315gsm (9.3oz) ripstop polycotton canvas cut from an ultra-wide roll, which lets us build 12m² (129 sq ft) of canopy with a single seam. Fewer seams, fewer leak paths, drier camp. The canvas is pre-treated for UV stability and mould and mildew resistance, with triple-stitched sleeves and reinforced attachment points at every load-bearing corner.

Wet it down before your first trip. The poly-cotton core spun thread swells and seals the stitch holes — a five-minute job that sets the canvas up for years of four-season use.

Build it out with walls

A 50mm (2") Velcro loop strip runs the full internal edge, ready for The Bush Company's canvas and mesh wall kits.

Run one wall as a windbreak on the exposed side. Run mesh to keep the sandflies out on a Cape York evening. Or close the whole thing in and turn 12m² (129 sq ft) of shade into a proper enclosed room with a view. The modular ecosystem is the point — you buy the awning once and shape it to the trip.

Mounting to your rig

The 270 XT MAX Mk2 ships with three heavy-duty adjustable L-brackets. One mounts to the stainless steel headstock at each end, with the third going in the middle for support across the span.

You need a minimum of 1.9m (6'3") between your front and rear mounting points. Most full-length platform racks, load bars and canopy racks clear this easily; some systems (the ARB base rack, for example) need additional hardware. The packed profile is 2300mm long x 230mm high (7'7" x 9.1"), so it sits low and tucks inside a standard roof line without overhang.

Running a Bush Company rooftop tent? The optional Awning To Tent brackets mount the awning directly to the tent for a tidy, low-profile touring setup.

Compatible with: dual-cab utes, 79 Series and wagon platforms, Troop Carriers, van conversions, canopied utes, and camper trailers — anywhere you can achieve 1.9m (6'3") bracket spacing and the roof payload to carry 33.5kg (73.9 lb).

Before you buy: check your roof payload

Straight talk. At 33.5kg (73.9 lb) plus brackets, plus rack, plus whatever else is up there, the 270 XT MAX Mk2 is a genuine payload decision. Check your vehicle's dynamic roof load rating before you order. If the numbers are tight, look at the 270 XT Mk2 (27.8kg / 61.3 lb) or the 180 XT MAX (26.5kg / 58.4 lb) instead — both run the same canvas and the same B-Tech™ Alloy DNA.

We'd rather you get the right awning than the biggest one.

Usage guidance

  • Secure the front and rear non-trussed arms with the supplied guy ropes and pegs in all conditions to prevent upward movement.
  • In heavy rain, run guy ropes off 1-tonne (2,205 lb) webbing straps between the arms to shed water and stop pooling.
  • Don't leave it deployed during snowfall — wet snow load stretches canvas.
  • Wet the canvas down thoroughly before first use.
  • Read the Care and Maintenance instruction on this website.

Key features

  • Freestanding 270° deployment — no poles required
  • 12m² (129 sq ft) of coverage across a 6067mm x 3100mm (19'11" x 10'2") footprint
  • Two hinge points with forward-folding front section for rear-of-vehicle coverage
  • B-Tech™ Alloy trussed arms with stainless steel hinges
  • 315gsm (9.3oz) ripstop polycotton canvas, single-seam construction, UV and mould treated
  • Setup and pack-down in under 60 seconds, one person
  • Rated to 50km/h (31 mph) gusts when pegged and guyed
  • 450gsm (13.3oz) PVC tonneau storage bag, oversized for easy repacking
  • 50mm (2") Velcro loop strip for modular wall kits
  • Three heavy-duty adjustable L-brackets included
  • Left or right hand fitment
  • Packed size 2300mm x 180mm (7'7" x 7.1"), weight 33.5kg (73.9 lb)
  • 2-year conditional warranty

Who it's for

Long-range tourers, families and overland crews running wagons, troopies, vans or canopied utes who want maximum shade around the whole rig, have 1.9m (6'3") of rack to mount it and the payload to carry it.

Specifications
  • Mount Type: Left or Right Side Available
  • Fabric Material: 310gsm Ripstop Polycotton Canvas: 9.3 oz
  • Frame Material: Extruded Aluminium Alloy
  • Awning Bag Material: 450gsm PVC Tonneau
  • External Dimensions (when open): 6067mm L x 3100mm W
  • Packed Dimension: 2300mm L x 180mm H
  • Coverage: 112 m² / 129 sq ft
  • Weight: 33.5 kg / 73.9 lb
  • Warranty: 2 Years Conditional

Vehicle Compatability

If mounting to a roof rack then the rack will typically need to be a minimum 1.9m / 6’3″ in length. We recommend placing a third bracket in the middle of the awning to provide additional support.

The 270 XT MAX Awning Mk2 is supplied with 3 Heavy DutyAdjustable L Brackets. One fitment bracket must be attached to the stainless steel headstock at each end.

Care & Maintenance

Using & Caring For Your Awning

Before Use:

We recommend that new awnings are thoroughly wet down before first use. This will ensure that your awning performs well in wet weather by allowing the poly/cotton core spun thread and canvas to swell ensuring the takeup of any potential leaks in the stitching.

Deploying & Packing Away:

  • When unzipping the awning, make sure the zippers are right to the top of the bag at each end and that the bottom corners of the bag are not caught on the awning frame.
  • When deploying your awning if the canvas seems excessively tight, STOP and check that the canvas is not caught on the hinge mechanism and that it has not slid too far one way in the sail-track on the awning frame.
  • When packing the awning away, ensure that the canvas is not pinched between the awning arms especially close to the hinge mechanism.

Cleaning Canvas & PVC Bag:

  • To clean canvas use a soft brush and cold water.
  • Do not expose to petrol, oils or harsh chemicals.
  • The PVC bag van be cleaned with standard car wash cleaning solution.

Cleaning mould:

Your awning canvas is pre-treated with mould and mildew resistance, but if mould/mildew does occur please follow these steps:

  • Allow mould to dry.
  • Remove surface mould with stiff bristle brush.
  • Vacuum the area.
  • Treat area with Oil of Clove spray (diluted spray can be purchased or can be mixed using a few drops of oil into a spray bottle of water).

Regular Maintenance & Checks:

Like any accessory used in extreme conditions regular maintenance is required to ensure the longevity of your awning, including:

  • Inspect awning hinges to identify any bolts that may need re-tightening.
  • Ensure that awning canvas is correctly located in the sail-rack on the backing frame to eliminate excessive tension on the canvas.
  • Inspect the attachment of the canvas to the ends of the awning arms.
  • Inspect canvas to identify any wear marks caused by incorrect packing of the canvas.

Stacked with features

RELAX IN 60 SECONDS

Set-up & pack down in under 60 seconds, no poles or guy ropes to deal with. Our tough stainless steel hinges make quick work of set-up, so you can kick back faster.

270° FREESTANDING COVERAGE

One of the biggest freestanding shades in the game, offering 270° of relentless coverage—perfect for spreading out or sharing the space with mates. The forward-folding arm ensures maximum shade where you need it most, making it the ultimate companion for any adventure.

ONE SEAM TO KEEP YOU DRY

Our single-seam solution means everyone stays dry and comfortable, with less chance of leaks. Manufactured in South Africa, our unique design method maximises canvas width and minimises seams, significantly reducing the potential for leakage.

BUILT TOUGH

Engineered for the extreme: our cutting-edge B-Tech™ Alloy frame & extrusions are built tough, providing ultimate strength and durability. Invest once, and own the most resilient awning out there.

WITHSTAND WILD WEATHER

Built to take on extreme conditions, our awning stands tall on its own—even when the weather turns wild. But for those extra windy days, we’ll keep you grounded with included guy ropes and pegs. Trust us—your car’s more likely to lift off than this beast.

NEXT LEVEL ACCESSORIES

Create your own space with privacy and protection from the elements thanks to the freestanding awning wall-kit accessories. Detachable walls are easy to use and turn your outdoor space into a cozy living room with a stunning view.

270 XT MAX Awning Mk2 VIDEOS

View all

Not sure which one is right for you?

Compare Our Freestanding Awnings

Person setting up a campsite on a beach with a vehicle having an extended awning.
270 XT MAX Awning Mk2
View
270 XT Awning Mk2 - The Bush Company
270 XT Awning Mk2
View
180 XT MAX Awning - The Bush Company
180 XT MAX Awning
View
Product variants
Product variants270 XT MAX Awning Options
  • Left Hand Side FItment,
  • Right Hand Side Fitment
270 XT Awning Option
  • Left Hand Side Fitment,
  • Right Hand Side Fitment
-
Weight
Weight
33.5Kg
27.8Kg
26.5Kg
Awning Coverage
Awning Coverage
12m2
8m2
8m2
Hinge Points
Hinge Points
2
1
2
Minimum Mounting Distance
Minimum Mounting Distance
1.9m
1.4m
1.9m

FAQS

What are the dimensions?

2300mm long x 230mm high — 7'7" x 9.1" — so it sits inside a standard roof line without overhang.

When open the awning is 12m² (129 sq ft), across a 6067mm x 3100mm footprint (19'11" x 10'2").

See dimension diagrams here:

Is the 270 XT MAX Awning Mk2 freestanding?

Yes. Once it's mounted to your vehicle, no poles or ground supports are needed to deploy it. Guy ropes and pegs are included and should be used to secure the non-trussed arms in all conditions.

How much shade does it give?

12m² (129 sq ft), across a 6067mm x 3100mm footprint (19'11" x 10'2"), wrapping 270° around the side and rear of your vehicle.

What canvas is it made from?

315gsm (9.3oz) ripstop polycotton, cut from an ultra-wide roll so the whole 12m² canopy is built with a single seam. It's pre-treated for UV stability, mould and mildew resistance and has a 1500mm waterhead rating.

How big is it packed away?

2300mm long x 230mm high — 7'7" x 7.1" — so it sits inside a standard roof line without overhang.

What's the difference between the 270 XT MAX Mk2 and the 270 XT Mk2?

The MAX has two hinge points and a forward-folding front section, giving 12m² (129 sq ft) of coverage and reaching further around the rear of the vehicle. The 270 XT Mk2 has a single pivot, 8m² (86 sq ft) of coverage, weighs 27.8kg (61.3 lb) instead of 33.5kg (73.9 lb), and needs only 1.4m (4'7") of bracket spacing instead of 1.9m (6'3").

Left hand or right hand fitment — which do I need?

Choose the side you want the awning to deploy from. Most tourers fit it to the side their camp kitchen or canopy door opens onto. A LH Awning is on the passenger side of a right hand drive vehicle.

What's the warranty?

2 years conditional.

Can I add walls?

Yes. A 50mm (2") Velcro loop strip runs the internal edge for canvas and mesh wall kits, so you can run a single windbreak or fully enclose the space.

Does it need poles?

No. Poles are only recommended when you're running the optional awning wall kits, and those poles are supplied with the wall kit.

How heavy is the awning?

33.5kg (73.9 lb), before brackets. Check your vehicle's dynamic roof load rating before ordering.

Can I install it myself?

Yes. Because of the 33.5kg (73.9 lb) weight you'll want a second set of hands for lifting and bolting. Fitting instructions are available in our Guides & Instructions section, or any Bush Company stockist can fit it for you.

What roof racks is it compatible with?

Any rack or set of load bars giving at least 1.9m (6'3") between your front and rear mounting points. Three adjustable L-brackets are included; the third mounts centrally for span support. Some systems, such as the ARB base rack, need additional hardware.

How do I install it? (video)

A copy of the fitting instructions for The Bush Company awnings is available for download here


The Bush Company or one of our stockists can install your awning, but if you choose to install the awning yourself please make sure that you have done the due diligence to ensure that it does not create any safety issues. Please also ensure you follow all standard safety precautions when undertaking the install.


You may find it useful to watch the following videos:

Didn’t find your answer?

Don't hesitate to contact us

Person setting up a campsite on a beach with a vehicle having an extended awning.
The Bush Company

270 XT MAX Awning Mk2

$2,162.00

270 XT MAX Awning Mk2 — the biggest freestanding shade in the Bush Company range

Twelve square metres. That's the number that matters. The 270 XT MAX Awning Mk2 deploys 12m² of UV- and water-resistant shade across a 6067mm x 3100mm footprint, wrapping your vehicle from the front door right around the rear — and it does it without a single upright pole touching the ground.

You're not pegging out a tarp. You're rolling into camp, swinging two trussed arms into position, and getting on with the fishing.

What makes the MAX different from the 270 XT Mk2

This is the question worth answering before you spend. Both are freestanding 270° awnings. The difference is in the hinges.

The 270 XT Mk2 runs a single pivot point — fast, simple, 8m², and brilliant for solo and duo touring. The 270 XT MAX Mk2 runs two hinge points and a forward-folding front section. That second hinge is what pushes coverage out to 12m² and lets the canvas reach further around the back of the vehicle, clearing canopy doors and covering a full rear kitchen setup.

More shade, more rear coverage, more room under it. The trade-offs are honest ones: 33.5kg on your roof instead of 27.8kg, and a 1.9m minimum bracket spacing instead of 1.4m. If your rack is shorter than 1.9m or your roof payload is tight, the 270 XT Mk2 is the smarter buy. If you're running a wagon, troopy, van or canopied ute and you want the whole camp covered, this is the one.

Freestanding means freestanding

No poles. No guy ropes in calm weather. Nothing to trip over at 2am, nothing to sink into soft sand, nothing to rattle loose on a corrugated track.

The B-Tech™ Alloy trussed arms carry the load themselves. That's the whole point of a truss — the geometry does the work, so the canvas stays tensioned and the frame stays put without ground support. Setup is a one-person job in under 60 seconds. Pack-down is the same in reverse, and the oversized PVC bag means you're not wrestling canvas back into a sleeve while the weather closes in.

When it does blow up, peg it out. The 270 XT MAX Mk2 is rated to 50km/h gusts when correctly pegged and guyed, and it ships with the guy ropes and pegs to do it.

B-Tech™ Alloy frame, engineered for the long haul

The frame is built from The Bush Company's exclusive B-Tech™ Alloy extrusion with stainless steel hinges and a powder-coated finish. Extruded alloy resists the torsional flex that kills welded frames on corrugations. Stainless hinges resist the salt that eats plated hardware on beach runs.

This is buy-once gear. The frame is the part you'll never think about again — which is exactly how it should be.

Australian owned, tested globally. Manufactured in South Africa in the same conditions that punish gear the way outback Australia does, then proven on Australian tracks by Australian tourers.

One seam. That's it.

Seams leak. Every stitched line across a canvas is a potential entry point, and most awnings on the market have several.

The 270 XT MAX Mk2 uses 315gsm ripstop polycotton canvas cut from an ultra-wide roll, which lets us build 12m² of canopy with a single seam. Fewer seams, fewer leak paths, drier camp. The canvas is pre-treated for UV stability and mould and mildew resistance, and has a 1500mm waterhead ratingwith triple-stitched sleeves and reinforced attachment points at every load-bearing corner.

Wet it down before your first trip. The poly-cotton core spun thread swells and seals the stitch holes — a five-minute job that sets the canvas up for years of four-season use.

Build it out with walls

A 50mm Velcro loop strip runs the full internal edge, ready for The Bush Company's canvas and mesh wall kits.

Run one wall as a windbreak on the exposed side. Run mesh to keep the sandflies out on a Cape York evening. Or close the whole thing in and turn 12m² of shade into a proper enclosed room with a view. The modular ecosystem is the point — you buy the awning once and shape it to the trip.

Mounting to your rig

The 270 XT MAX Mk2 ships with three heavy-duty adjustable L-brackets. One mounts to the stainless steel headstock at each end, with the third going in the middle for support across the span.

You need a minimum of 1.9m (6'3") between your front and rear mounting points. Most full-length platform racks, load bars and canopy racks clear this easily; some systems (the ARB base rack, for example) need additional hardware. The packed profile is 2300mm long x 230mm high, so it sits low and tucks inside a standard roof line without overhang.

Running a Bush Company rooftop tent? The optional Awning To Tent brackets mount the awning directly to the tent for a tidy, low-profile touring setup.

Compatible with: dual-cab utes, 79 Series and wagon platforms, Troop Carriers, van conversions, canopied utes, and camper trailers — anywhere you can achieve 1.9m bracket spacing and the roof payload to carry 33.5kg.

Before you buy: check your roof payload

Straight talk. At 33.5kg plus brackets, plus rack, plus whatever else is up there, the 270 XT MAX Mk2 is a genuine payload decision. Check your vehicle's dynamic roof load rating before you order. If the numbers are tight, look at the 270 XT Mk2 (27.8kg) or the 180 XT MAX (26.5kg) instead — both run the same canvas and the same B-Tech™ Alloy DNA.

We'd rather you get the right awning than the biggest one.

Usage guidance

Key features

Who it's for

Long-range tourers, families and overland crews running wagons, troopies, vans or canopied utes who want maximum shade around the whole rig, have 1.9m of rack to mount it and the payload to carry it.

270 XT MAX Awning Options

  • Left Hand Side FItment
  • Right Hand Side Fitment
View product

  • 2-Year Warranty

    Adventure confidently.

  • Engineered to Last

    Exclusive B-Tech™ Alloy Extrusion Technology

  • Made in South Africa

    Australian Owned, Tested Globally.

  • Online Support Centre

    Expert Help and Advice.
